24V DC 2 CHANNEL RTD INPUT MODULE.
Description: The 1734-IR2 is a Resistance Temperature Detector (RTD)input module that is part of Allen-Bradley’s POINT IO product family. This module features Two (2) single-ended, non-isolated input channels. Each channel supports 100 Pt α = 0.00385; 200 Pt α = 0.00385; 100 Pt α = 0.003916; 200 Pt α = 0.003916; 10 Cu α = 0.00427; 100 Ni α = 0.00618; 120 Ni α = 0.00618 and 120 Ni α = 0.00672 sensors. Aside from RTD sensor inputs, this module also supports direct wiring of 0-600 Ω analog signal. This module has a 16-bit resolution.
| Brand: |
Allen-Bradley |
| Module Location: |
1734-TB, 1734-TBS, 1734-TOP, or 1734-TOPS wiring base assembly |
| Part Number/Catalog No. |
:1734-IR2 |
| Series: |
POINT I/O |
| Module Type: |
RTD / Resistance input module |
| Power Dissipation: |
1.0 W @ 28.8V DC |
| Keyswitch Position: |
6 |
| Inputs: |
2 Single-Ended, Non-Isolated |
| Conversion Type: |
Delta Sigma |
| Weight: |
0.08 pounds (0.036 kilograms) |
| Dimensions (H x W x D): |
2.21 x 0.47 x 2.97 inches |
