As of November 23, 2023
Specifications and design of the products are subject to change without notice for the product improvement.
Spec Detail
| Item | Specifications |
|---|---|
| Product Number | FD-L52 |
| Part Number | FD-L52 |
| Material | Fiber core: Acrylic Sheath: Polyethylene Fiber head: Polycarbonate Lens: Polyalylate |
| Weight | Net weight: 15 g approx. |
| Applicable amplifiers | FZ-11, FZ-11P |
| Sensing range | 8 to 11 mm 0.315 to 0.433 in (Note) The sensing range of each fiber is the range for which white non-glossy paper can be detected at the sensitivity for which teaching has been done with a white non-glossy paper (50 x 50 mm 1.969 x 1.969 in ) at the respective rated setting distance and at the 16th grade of tolerance. |
| Setting distance | 10 mm 0.394 in(fixed) |
| Spot diameter (at setting distance) | dia. 2.5 mm dia. 0.098 in |
| Allowable bending radius | R25 mm R0.984 in or more (Note) If the fiber cable is bent at less than R25 mm R0.984 in or less, the detectability may deteriorate. |
| Fiber cable length | 1 m 3.281 ft |
